Data Editing
Product Reference Guide
251
Table 36
STEP ACTION EXAMPLES
1. Scan the ENTER/EXIT bar code
(Scanner enters Programming Mode)
2.
Determine placement of the
Label ID
characters BEFORE or
AFTER with regard to scanned
data using
Label ID
Control, starting on page
59
Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix
3.
Scan the bar code selecting the
symb
ology type you wish to
designate label ID characters
for using
Label ID
Symbology Selection − 1D
Symbologies, starting on
page 60
.
DataBar
Omnidirectional
Code 39 Interleaved 2 of 5 Code 32
4.
Custom Label ID example
(desired characters):
D B * = C 3 + P H
5.
Find hex equivalents from the
ASCII Chart
(inside back
cover), then scan in these
digit
s/characters using the bar
codes in the section:
Keypad, starting on page
291
. If you make a mistake
before the last character, scan
the CANCEL bar code to abort
and not save the entry string.
You can then start again at the
beginning.
44 42 2A 3D 43 33 2B 50 48
6. Scan the ENTER/EXIT bar code
(Scanner exits Label ID entry)
7.
Scan the ENTER/EXIT bar code
once ag
ain
(Scanner exits Programming Mode)
Result:
DB*[bar code
data]
[bar code
data]=C3
+[bar code data] [bar code data]PH
. Label ID Examples
