40mm Media Hub
A media hub that will accommodate 40mm media cores.
Powered Internal Rewinder
An power assisted internal mechanism to wind 8-inch outer diameter rolls of printed labels, or
the label backing material for the Peel and Present option.
RFID (UHF) Options (4" wide models only)
Several levels of RFID options are available to fit your current and future needs.
> RFID - Factory Installed - complete and functional option direct from the factory.
> RFID - Ready - Factory installed antenna and wiring, for use with future RFID module purchase.
> RFID - Full Upgrade - Complete Kit, upgrades any standard printer with RFID capabilities.
External Media Rewinder (specify voltage requirement when ordering)
A precision-crafted, bi-directional rewinding mechanism with device-dependant features:
> DMXREW1 – accommodates 1 to 4-inch (25 to 101 mm) diameter cores; accepts a maximum label
width of 4.5 inches (114 mm); and, rewinds to a 8-inch (203 mm) maximum outer diameter at 10
inches per second.
> DMXREW2 – accommodates 3-inch (76 mm) diameter cores; accepts a maximum label width of 9.5
inches (241 mm); and, rewinds to a 12-inch (304 mm) maximum outer diameter at 30 inches per
second.
ILPC Fonts
A font set that allows International Language Print Capability consisting of one of the following:
> CG-Times (western European) Scalable font
> Kanji Gothic B Scalable font
> Simplified Chinese GB Scalable font
> Korean Hangul font
Option Installation
The following table lists the available options and the recommended qualification level of the
installer. For detailed information concerning a specific option, contact your dealer or Datamax
Technical Support.
Option Installation Requirement Level
40mm Media Hub Factory Installed
Thermal Transfer Operator
Present Sensor Operator
Peel and Present Option Operator
Media Cutter Operator
Internal Rewinder Operator
External Rewinder Operator
ILPC Fonts DMX Certified Technician
RFID DMX Certified Technician
