Datamax H Class User Manual

95
Advanced Entry Calibration
ADVANCED ENTRY should only be used when the Standard Calibration method has failed.
To facilitate the placement of the media sensor, the printhead assembly can be raised. During
this procedure, sampled readings will be used to manually establish the best gain algorithm for
sensing the media. Before calibrating, ensure that the Advanced Menu system is enabled, and
that the Media Sensor Type has been selected. Then, use the steps below and the displayed
prompts to guide you through the procedure:
Step Action
Displayed
Message
Comment(s)
1
Press the MENU Button.
CANNOT
CALIBRATE
-or-
UNCALIBRATED
See MENU ORGANIZATION for
menu navigation tips.
2
Press the ENTER Key to access
MEDIA SETTINGS, and then use
the UP Button to scroll to SENSOR
CALIBRATION.
MEDIA SETTINGS
This is the MEDIA SETTINGS menu
branch.
3
Press the ENTER Key to access
SENSOR CALIBRATION. Use the
UP Button to scroll to ADVANCED
CALIBRATION and press the
ENTER Key.
ADVANCED
CALIBRATION
You are beginning ADVANCED
ENTRY calibration. Press the ESC
Key to abort this procedure.
4
Scroll to TRAN SENSOR GAIN (or
REFL SENSOR GAIN, if using
reflective media) then press the
ENTER Key.
TRAN SENSOR
GAIN
(0 -
31)
YYY
25
The examples that follow detail the
calibration of die-cut media; however,
unless otherwise noted, the procedure
for calibrating reflective media is the
same.
5
Install roll media or box media.
Position the Media Sensor under
the label, then lower and latch the
Printhead Assembly.
TRAN SENSOR
GAIN
(0 -
31)
YYY
25
If using preprinted media, ensure the
label area over the sensor is free of
text, graphics, lines, etc.

Datamax H Class Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Interface	Ethernet, Wireless
Media Sensor	Reflective
Media Types	Labels, Tags
Resolution	203 dpi
Media Thickness	0.002 to 0.01 inches (0.05 to 0.25 mm)
