Datamax H Class User Manual

47
Print Control
Within the Print Control branch, the following menu selections are available:
• Heat
• Print Speed
• Feed Speed
• Reverse Speed *
• Slew Speed *
• Row Offset
• Column Offset
• Present Distance
• Custom Adjustments *
Note:
Items denoted with an asterisk (*) are only accessible through the Advanced Menu.
The menu selections are defined as follows:
DISPLAYED
ITEM
ITEM DESCRIPTION
HEAT
Controls the ‘burn time’ (0 - 30) of the printhead (also equivalent to the Heat
setting in many software labeling programs), where:
10 Is the Default Setting.
PRINT SPEED
Controls the rate of label movement (2.0 - XX.X inches per second, model
dependent) during printing, where:
8.0 in/sec Is the Default Setting.
FEED SPEED
Controls the rate of label movement (2.0 - 12.0 inches per second) between
printing areas, where:
8.0 in/sec Is the Default Setting.
REVERSE
SPEED
Controls the rate of label movement (2.0 - 5.0 inches per second) during backup
positioning, where:
4.0 in/sec Is the Default Setting.
SLEW SPEED
Controls the rate of label movement (2.0 - 16.0 inches per second) between
printing areas when using the GPIO function, where:
8.0 in/sec Is the Default Setting.
