96
Step Action
Displayed
Message
Comment(s)
6
Create a table with 32 rows (one
for each of the Gain Numbers that
will be tested) and four columns
with headings similar to the one
shown below.
Use the UP, DOWN, LEFT, and
RIGHT Buttons to set the Gain
Number to 00 and then press the
ENTER Key.
Record the reading as a Label
Value for Gain Number 00 in your
table.
Increment the Gain Number by
one, press the ENTER Key, note
the Label Value. Repeat this
process to document the Label
Values for the thirty remaining
Gain Numbers.
Calibration Table
Gain
Number
Label
Value
TOF
Value
Difference
Value
00 252
01 250
02 248
... ...
31 131
TRAN SENSOR
GAIN
(0 -
31)
250
00
The YYY value represents the current
sensor reading. (The numbers given
in this procedure are meant only as
samples -- actual measurements will
vary.)
Notes:
(1) Do not
position the Media Sensor
under a perforation.
(2) The LEFT and RIGHT Buttons
shift the cursor position.
7
Raise the printhead assembly and
proceed according to your media
type:
• Die-cut stock -- Remove a
label or two from the liner
material, and then position
the liner over the Media
Sensor.
• Notched stock -- Position
the notch over the Media
Sensor.
• Reflective stock -- Position
the black mark over the
Media Sensor.
Lower and latch the Printhead
Assembly.
TRAN SENSOR
GAIN
(0 -
31)
YYY
31
Notes:
(1) Do not
position the Media Sensor
under a perforation.
(2) Do not
move the position of the
Media Sensor after it has been
adjusted.
