Datamax H Class - Driver and Port Setup; Windows 2000 Driver and Port Installation

17
Driver and Port Setup
Windows 2000 Driver and Port Installation
1
Start the Windows
“Add Printer Wizard”.
The following screen
should appear, click
‘Next>’.
2
Make sure that
‘Local Printer’ is
selected and then
click ‘Next’.
3
Select on ‘Create a
new port:’ and then
select ‘Standard
TCP/IP Port’ from
the drop down
menu. Click ‘Next’
4
Click ‘Next’.
5
In the ‘Printer
Name or IP
Address:’ field enter
the IP address of
your printer. The
‘Port Name’ field
does not
need to be
changed. When
finished click ‘Next’.
6
Make sure
‘Standard’ is
selected and then
click ‘Next’.
7
Confirm your settings
and then click ‘Finish’.
8
Click on ‘Have
Disk’.
