Datamax H Class User Manual

45
LABEL LENGTH
Determines the length of the label (0 - 99.99 inches) when the SENSOR TYPE is
set to CONTINUOUS, where:
04.00 inches Is the Default Setting.
MAXIMUM
LABEL LENGTH
Sets the length of media (0 - 99.99 inches) that the printer will attempt to feed
between the sensing of TOF gaps or marks (when the Sensor Type is set to GAP
or REFLECTIVE) before a TOF Fault is declared, where:
16.00 inches Is the Default Setting.
Note:
It is recommended that Maximum Label Length be at least 2.5 to 3 times the physical length
of the label.
PAPER EMPTY
DISTANCE
Sets the length of media (0 - 99.99 inches) the printer will attempt to feed before
an Out Of Stock Fault is declared. This setting should be set longer then the
actual label size when using clear or translucent media, where:
00.25 inches Is the Default Setting.
LABEL WIDTH
Sets the maximum printable width (0.75 - 4.10 inches). Objects extending beyond
this setting will NOT print, where:
4.10 inches Is the Default Setting.
RIBBON LOW
OPTIONS
Define the printer response when THERMAL TRANSFER mode is selected and
the ribbon supply begins to diminish.
RIBBON LOW
DIAMETER
Sets the threshold diameter (1.00 - 2.00 inches) of the depleted ribbon supply that
will trigger a Low Ribbon Warning prompt, where:
1.38 inches Is the Default Setting.
PAUSE ON
RIBBON LOW
Allows the printer to enter a paused condition when the Ribbon Low Diameter
threshold is exceeded, where:
ENABLE Sets the printer to pause when a Ribbon Low Diameter condition is detected; the
PAUSE Key must be pressed to proceed with the print job.
DISABLE No action is required by the operator; printing can continue until a Ribbon Fault is
declared.
SENSOR
CALIBRATION
Selects the method used to adjust the printer to sense media, where:
PERFORM
CALIBRATION
Sets the values for media sensing via internal printer calculations, as described in
the STANDARD CALIBRATION procedure.
ADVANCED
ENTRY
Sets the media sensor values via manual entry (typically for custom or hard to
calibrate label stocks), as described in the ADVANCED ENTRY CALIBRATION
where:
PAPER
SENSOR
LEVEL
Establishes the threshold for the paper value (0 - 255), where 170 is the Default
Setting.
REFL PAPER
LEVEL
Establishes the threshold for the reflective value (0 - 255), where 170 is the
Default Setting.
GAP SENSOR
LEVEL
Establishes the threshold for the gap value (0 - 255), where 040 is the Default
Setting.
MARK SENSOR
LEVEL
Establishes the threshold for the mark value (0 - 255), where 040 is the Default
Setting.
