Page #15 background image
11
I-Class Mark II Maintenance Manual
Ad
j
ustments and Maintenance
Advanced Entry Calibration (continued)
Step Action Displayed Message Comment
N
Press the ESC button.
Use the buttons to scroll to PAPER
SENSOR LEVEL (or if using
reflective media, REFL PAPER
LEVEL) and then press ENTER.
Use the buttons to set the Paper
value determined in Step M and
then press ENTER.
PAPER SENSOR LEVEL
(0 - 255)
173
This is the Paper value.
O
Press the ESC button.
Scroll to GAP SENSOR LEVEL (or, if
using reflective media, MARK
SENSOR LEVEL) and then press
ENTER.
Set the Gap (or Mark) value
determined in Step M and then
press ENTER.
GAP SENSOR LEVEL
(0 - 255)
042
This is the Gap (or Mark) value.
P
Press the ESC button.
Scroll to EMPTY SENSOR LEVEL
and then press ENTER.
Set the Empty value determined in
Step M and then press ENTER.
EMPTY SENSOR LEVEL
(0 - 255)
009
This is the Empty value.
Q
Press the EXIT button and, when
prompted, press YES at the SAVE
CHANGES prompt.
OFFLINE
The procedure is finished, the
process almost complete.
