2
I-Class Mark II Maintenance Manual
Overview
1.1 About the Printer
The following drawing highlights the major components of the printer.
Cover Assembly
Media Hub
Internal Rewind
Ribbon Supply Hub
Ribbon Take-up Hub
Front Panel
Printhead Assembly
Filler Block
Platen Block
Printhead
Media Sensor
Platen
Leveling Cam
Printhead Latch
Ribbon Idler
Media Idler
Media Guide
Main PCB
Power Supply
Drive Motor
Drive Gears
Option Cards
