Datamax I-Class Mark II Maintenance Manual

17
I-Class Mark II Maintenance Manual Ad
j
ustments and Maintenance
WARNING
NEVER exceed the recommended Printhead Voltage; permanent damage or
shortened service life can result.
Printhead Voltage Adjustment Table
Printer
Model
Printhead Resistance
(ohms)
Printhead Voltage
(+/- 0.1 Volt DC)
572 - 597 22.4
598 - 622 22.9
623 - 647 23.3
648 - 672 23.8
673 - 697 24.2
698 - 722 24.7
723 - 747 25.1
I4212e
748 - 772 25.5
947 – 989 22.4
990 – 1030 22.9
1031 – 1072 23.4
1073 – 1114 23.8
1115 – 1156 24.2
1157 – 1197 24.7
1198 – 1239 25.1
I4310e
1240 – 1281 25.5
1530 – 1598 22.4
1599 – 1665 22.9
1666 – 1733 23.4
1734 – 1800 23.8
1801 – 1868 24.2
1869 – 1935 24.7
1936 – 2003 25.1
I4606e
2004 – 2070 25.5

Datamax I-Class Mark II Specifications

General

Power Supply	100-240 VAC, 50-60 Hz
Print Resolution	203 dpi
Print Width	4.09 inches
Memory	16 MB DRAM, 8 MB Flash
Connectivity	USB, Serial, Ethernet
Media Handling	Roll-fed
Media Width	1.0" – 4.65" (25.4 mm – 118 mm)
Media Thickness	0.0025" – 0.010" (0.0635 mm – 0.254 mm)
Ribbon Width	1.0" – 4.5" (25.4 mm – 114.3 mm)
Ribbon Length	1968 feet (600 meters)
Print Speed	up to 12 ips
Dimensions	12.7" H x 12.6" W x 18.6" D (322.6 mm H x 320 mm W x 472.4 mm D)
