Datasat LS10 - Bass Management Setup Procedure

LS10 Installation and Operating Guide Page 56
LS10 Installation & Operating Guide Document # 9301H66300 Ver. 1.01
3.9.2 Bass Management Setup Procedure
1. Select the Speaker Configuration (that matches your installation) from the drop down at the upper
right. See Figure 38.
Table 13.
Bas
s Management Speaker Configuration
Speaker
Configu-
ration
Channels
2.0 L R
2.1 L R
SUB 1 SUB2
3.1 L R C
SUB1 SUB2
4.1 L R Ls Rs
SUB1 SUB2
5.1 L R C Ls Rs
SUB 1 SUB2
7.1 h L R C Ls Rs HL HR
SUB1 SUB2
7.1 w L R C Ls Rs LW Rw
SUB1 SUB2
9.1 hw L R C Ls Rs HL HR Lw Rw
SUB 1 SUB 2
7.1 L R C Ls Rs Lb Rb
SUB1 SUB 2
9.1h L R C Ls Rs Lb Rb HL HR
SUB1 SUB 2
9.1w L R C Ls Rs Lb Rb Lw Rw
SUB1 SUB 2
11.1 hw L R C Ls Rs Lb Rb HL HR Lw Rw
SUB1 SUB 2
Auro 9.1 L R C Ls Rs HL HR HLs HRs
SUB1 SUB 2
Auro 10.1 L R C Ls Rs HL HR Hc HLs HRs
SUB1 SUB 2
Auro 11.1 L R C Ls Rs HL HR Hc HLs HRs T
SUB1 SUB 2
Auro 11.1
(7+4)
L R C Ls Rs Lb Rb HL HR HLs HRs
SUB1 SUB 2
Auro 13.1* L R C Ls Rs Lb Rb HL HR Hc HLs HRs T
SUB1 SUB 2
*Note: When Auro 13.1 is selected, a checkbox labeled “Phantom HC” appears on the Bass
Management screen, for selecting a 13.1 configuration without the HC speaker. When selected, the HC
channel is downmixed with HL and HR.
2. Activate Enable Bass Management. This is the master enable that turns on all Bass Management
functions.
3. Select the Subwoofer Configuration (from the dropdown) with the appropriate number and position
of the subwoofers used. The subwoofer configuration option configures the bass management with
the number of subwoofer channels from 0 to 2.
Table 14. Bass Management Subwoofer Configuration
