Table 7. Parametric EQ

Controls Description

Chan

Tap the Chan button and a screen opens where you can directly

select a channel. Alternatively, you can tap the - or + buttons to

cycle the Chan button through the available channels.

PinkNoise On/Off

Tap this button to turn pink noise on/off for the selected channel.

Filter

Tap to select, then use the up/down arrow keys to select the

desired filter (of 10 total).

Filter

Enabled/Disabled

Tap this button to enable or disable the selected filter. Filter

disabled in effect turns off the selected filter.

Freq (Hz)

Tap to select, then use the computer keyboard to enter the

numbers. Alternatively, use the up/down arrow keys to adjust the

frequency for this filter. Hold down the arrow key to quickly move

upward/downward through the frequencies (from 20Hz to 20kHz).

Note: If you have no keyboard access, double-click on the Freq

field open a virtual keyboard where you can directly enter the

desired frequency.

Tap to select, then use the up/down arrow keys to adjust the Q

for this filter. Hold down to arrow key to quickly move

upward/downward through the range (0.7 to 5.0).

Gain

Tap to select, then use the up/down arrow keys to adjust the

Gain for this filter. Hold down the arrow key to quickly move

upward/downward through the range (-6.0 to +6.0 dB).

3.6.3 EQ Copy or Clear

On the Setup Home screen, select between EQ1 and EQ2 in the dropdown.

Press the Copy EQ button, and the Copy / Clear EQ screen appears.
