7.2.40.12 Sub-Register 0x27:2C – RXPACC_NOSAT
Digital debug register. Unsaturated accumulated preamble
symbols.
Register file: 0x27 – Digital receiver configuration, sub-register 0x2C is a read-only debug value containing a
count of accumulated preamble symbols without saturation. Note that the accumulated SFD symbols minus
two (two SFD symbols are always ignored in the receiver) are also included.
7.2.41 Register file: 0x28 – Analog RF configuration block
Register map register file 0x28 is concerned with the low-level configuration of the IC analog blocks. It
contains a number of sub-registers. An overview of these is given by Table 36. Each of these sub-registers is
separately described in the sub-sections below.
Table 36: Register file: 0x28 – Analog RF configuration block overview
RF Configuration Register
Analog RX Control Register
Analog TX Control Register
7.2.41.1 Sub-Register 0x28:00 – RF_CONF
RF Configuration Register
Register file: 0x28 – Analog RF configuration block, sub-register 0x00 is a 32-bit configuration register for the
transceiver. Please take care not to write other values to the reserved area of this register as doing so may
cause the DW1000 to malfunction.
