Table 1. Screw list (continued)
Component Secured to Screw type Quantity Screw image
Front-handle bar Chassis #6-32x6.5 14
Bottom-handle bar Chassis #6-32x6.5 14
Front bezel Chassis #6-32x6 4
Front bezel Chassis 6-32x5.2 3
Optical-drive eject-
button board
Chassis #6-32x6 2
Rear bezel Chassis #6-32x6 4
Rear bezel Chassis M3x5 2
Base panel Chassis #6-32x6 4
Base panel Chassis #6-32x6 5
Antennas Chassis #6-32x6 6
13
