Virtual Router Redundancy Protocol (VRRP) | 1483
Figure 63-3. Command Example: show vrrp
Table 63-2. Command Example Description: show vrrp
Line Beginning with Description
GigabitEthernet... Displays the Interface, the VRRP group ID, and the network address.
If the interface is no sending VRRP packets,
0.0.0.0 appears as the network
address.
VRF VRF instance to which the interface (on which the VRRP group is configured) belongs
State: master... Displays the interface’s state:
•
Na/If (not available),
•
master (MASTER virtual router)
•
backup (BACKUP virtual router)
the interface’s priority and the IP address of the MASTER.
Hold Down:... This line displays additional VRRP configuration information:
•
Hold Down displays the hold down timer interval in seconds.
•
Preempt displays TRUE if preempt is configured and FALSE if preempt is not
configured.
•
AdvInt displays the Advertise Interval in seconds.
FTOS>show vrrp
------------------
GigabitEthernet 12/3, VRID: 1, Net: 10.1.1.253
VRF: 0 default-vrf
State: Master, Priority: 105, Master: 10.1.1.253 (local)
Hold Down: 0 sec, Preempt: TRUE, AdvInt: 1 sec
Adv rcvd: 0, Adv sent: 1862, Gratuitous ARP sent: 0
Virtual MAC address:
00:00:5e:00:01:01
Virtual IP address:
10.1.1.252
Authentication: (none)
Tracking states for 1 interfaces:
Up GigabitEthernet 12/17 priority-cost 10
------------------
GigabitEthernet 12/4, VRID: 2, Net: 10.1.2.253
VRF: 0 default-vrf
State: Master, Priority: 110, Master: 10.1.2.253 (local)
Hold Down: 10 sec, Preempt: TRUE, AdvInt: 1 sec
Adv rcvd: 0, Adv sent: 1862, Gratuitous ARP sent: 0
Virtual MAC address:
00:00:5e:00:01:02
Virtual IP address:
10.1.2.252
Authentication: (none)
Tracking states for 2 interfaces:
Up GigabitEthernet 2/1 priority-cost 10
Up GigabitEthernet 12/17 priority-cost 10
------------------
GigabitEthernet 7/30, IPv6 VRID: 3, Version: 3, Net: fe80::201:e8ff:fe01:95cc
VRF: 0 default-vrf
State: Master, Priority: 100, Master: fe80::201:e8ff:fe01:95cc (local)
Hold Down: 0 centisec, Preempt: TRUE, AdvInt: 100 centisec
Accept Mode: FALSE, Master AdvInt: 100 centisec
Adv rcvd: 0, Bad pkts rcvd: 0, Adv sent: 310
Virtual MAC address:
00:00:5e:00:02:01
Virtual IP address:
2007::1 fe80::1
Tracking states for 2 resource Ids:
2 - Up IPv6 route, 2040::/64, priority-cost 20, 00:02:11
3 - Up IPv6 route, 2050::/64, priority-cost 30, 00:02:11
