ASDA-B2 Chapter 6 Control Modes of Operation
Revision September 2013 6-9
Electronic Gear Ratio
Corresponding travel distance per
pulse
When the electronic
gear ratio is not
used
=
1
1
=
3x1000
4x2500
=
3000
10000
m
When the electronic
gear ratio is used
=
10000
3000
=1 m
6.2.4 Low-pass Filter
Relevant parameters:
P1-08 PFLT
Smooth Constant of Position Command (Low-
pass Filter)
Address: 0110H
0111H
Operation
Interface:
Keypad/Software Communication
Related Section:
Section 6.2.4
Default: 0
Control
Mode:
PT
Unit: 10ms
Range: 0 ~ 1000
Data Size: 16-bit
Display
Format:
Decimal
Settings: 0: Disabled
For example: 11=110 msec
PFL
T
Target position
Position
Time (ms)
