Delta Electronics ASDA-B2 series User Manual

Chapter 2 Installation and Storage ASDA-B2
2-8 Revision September 2013
2.7 Regenerative Resistor
Built-in Regenerative Resistor
When the output torque of servo motor in reverse direction of motor rotation speed, it
indicates that there is a regenerative power returned from the load to the servo drive. This
power will be transmitted into the capacitance of DC Bus and result in rising voltage. When
the voltage has risen to some high voltage, the servo system need to dissipate the extra
energy by using a regenerative resistor. ASDA-B2 series servo drive provides a built-in
regenerative resistor and the users also can connect to external regenerative resistor if
more regenerative capacity is needed.
The following table shows the specifications of the servo drive’s built-in regenerative
resistor and the amount of regenerative power (average value) that it can process.
Built-in Regenerative Resistor Specifications
Servo Drive
(kW)
Resistance (Ohm)
(parameter P1-52)
Capacity (Watt)
(parameter P1-53)
Regenerative Power
processed by built-in
regenerative resistor
(Watt) *
1
Min. Allowable
Resistance (Ohm)
0.1 - - - 60
0.2 - - - 60
0.4 100 60 30 60
0.75 100 60 30 60
1.0 40 60 30 30
1.5 40 60 30 30
2.0 20 100 50 15
3.0 20 100 50 15
*1 Regenerative Power Calculation: The amount of regenerative power (average value)
that can be processed is rated at 50% of the capacity of the servo drive's built-in
regenerative resistor. The regenerative power calculation method of external regenerative
resistor is the same.
When the regenerative power exceeds the processing capacity of the servo drive, install
an external regenerative resistor. Please pay close attention on the following notes when
using a regenerative resistor.
1.
Make sure that the settings of resistance (parameter P1-52) and capacity (parameter
P1-53) is set correctly.
2.
When the users want to install an external regenerative resistor, ensure that its
resistance value is the same as the resistance of built-in regenerative resistor. If
combining multiple small-capacity regenerative resistors in parallel to increase the
regenerative resistor capacity, make sure that the resistance value of the
regenerative resistor should comply with the specifications listed in the above table.
3.
In general, when the amount of regenerative power (average value) that can be
