ASDA-B2 Chapter 2 Installation and Storage
Revision September 2013 2-5
2.5 Circuit Interrupter and Fuse Current Recommended Value
Caution: Please use circuit interrupter and fuse which are recognized by and
comply with the UL or CSA standards.
Servo Drive Model Recommended Breaker Recommended Fuse (Class T)
Operation Mode General General
ASD-B2-0121-B 5A 5A
ASD-B2-0221-B 5A 6A
ASD-B2-0421-B 10A 10A
ASD-B2-0721-B 10A 20A
ASD-B2-1021-B 15A 25A
ASD-B2-1521-B 20A 40A
ASD-B2-2023-B 30A 50A
ASD-B2-3023-B 30A 70A
NOTE
1) When using a GFCI (Ground Fault Circuit Interrupter), select a current sensor with sensitivity of equal to
or more than 200mA, and not less than 0.1-second detection time to avoid nuisance tripping.
