Delta Electronics ASDA-B2 series User Manual

Chapter 1 Unpacking Check and Model Explanation ASDA-B2
1-6 Revision September 2013
1.3 Servo Drive and Servo Motor Combinations
The table below shows the possible combination of Delta ASDA-B2 series servo drives
and ECMA series servo motors. The boxes () in the model names are for optional
configurations. (Please refer to Section 1.2 for model explanation)
Power Servo Drive Servo Motor
100W
ASD-B2-0121
-
ECMA-C20401S（S=8mm）
200W
ASD-B2-0221-
ECMA-C20602S（S=14mm）
400W
ASD-B2-0421
-
ECMA-C20604S (S=14mm)
ECMA-CM0604S (S=14mm)
ECMA-C208047 (7=14mm)
ECMA-E21305S (S=22mm)
ECMA-G21303S (S=22mm)
750W
ASD-B2-0721-
ECMA-C20807S (S=19mm)
ECMA-C20907S (S=16mm)
ECMA-G21306S (S=22mm)
ECMA-GM1306S (S=22mm)
1000W
ASD-B2-1021
-
ECMA-C21010S (S=22mm)
ECMA-C20910S (S=16mm)
ECMA-E21310S (S=22mm)
ECMA-G21309S (S=22mm)
ECMA-GM1309S (S=22mm)
1500W
ASD-B2-1521-
ECMA-E21315S (S=22mm)
2000W
ASD-B2-2023
-
ECMA-C21020S (S=22mm)
ECMA-E21320S (S=22mm)
ECMA-E21820S (S=35mm)
3000W
ASD-B2-3023-
ECMA-E21830S (S=35mm)
ECMA-F21830S (S=35mm)
The servo drives shown in the above table are designed for use in combination with the
specific servo motors. Check the specifications of the drives and motors you want to use.
Also, please ensure that both the servo drive and motor are correctly matched for size
(power rating). If the power of motor and drive is not within the specifications, the drive
and motor may overheat and servo alarm would be activated. For the detail specifications
of servo drives and motors, please refer to Chapter 11 “Specifications”.
The drives shown in the above table are designed according to the three multiple of rated
current of motors shown in the above table. If the drives which are designed according to
the six multiple of rated current of motors are needed, please contact our distributors or
your local Delta sales representative.
