Delta Electronics ASDA-B2 series User Manual

ASDA-B2 Chapter 1 Unpacking Check and Model Explanation
Revision September 2013 1-5
ECMA Series Servo Motor
ECMA-C10602ES
Type of Shaft
Diameter
and
Oil Seal
w/o
Brake
w/o Oil
Seal
with
Brake
w/o Oil
Seal
w/o
Brake
with Oil
Seal
With
Brake
With Oil
Seal
Round Shaft
(with fixed
screw holes)
A B C D
Keyway
E F G H
Keyway
(with fixed
screw holes)
P Q R S
Standard Shaft Diameter: S
Specific Shaft Diameter: 3=42mm, 7=14mm
Rated Power Output
01:100W 05:500W 10:1.0kW
02:200W 06:600W 15:1.5kW
03:300W 07:700W 20:2.0kW
04:400W 09:900W 30:3.0kW
Motor Frame Size
04:40mm 09:86mm 18:180mm
06:60mm 10:100mm
08:80mm 13:130mm
Name of the Series
Rated Voltage and Rated Speed
C
= 220V/3,000 rpm; E = 220V/2,000 rpm;
F
= 220V/1,500 rpm; G = 220V/1,000 rpm;
Encoder Type
1: Incremental, 20-bit
2: Incremental, 17-bit
M: Magnetic encoder, 13-bit
Servo Type
A: AC Servo
Product Name
ECM: Electronic
Commutation Motor
