Delta Electronics ASDA-B2 series User Manual

Chapter 3 Connections and Wiring ASDA-B2
3-2 Revision September 2013
3.1.2 Servo Drive Connectors and Terminals
Terminal
Identification
Terminal
Description
Notes
L1c, L2c
Control circuit
terminal
Used to connect single-phase AC control circuit
power. (Control circuit uses the same voltage as the
main circuit.)
R, S, T
Main circuit
terminal
Used to connect single-phase or three-phase AC main
circuit power depending on connecting servo drive
model.
U, V, W
FG (
)
Servo motor
output
Used to connect servo motor
Terminal
Symbol
Wire Color Description
U Red
Connecting to
three-phase
motor main
circuit cable.
V White
W Black
FG( )
Green
Connecting to
ground terminal
(
) of the
servo drive.
P , D, C,
Regenerative
resistor terminal
or braking unit
Internal resistor
Ensure the circuit is closed between
P
and D, and the circuit is open
between P
and C.
External resistor
Connect regenerative resistor to P
and C, and ensure an open circuit
between P
and D.
External braking
unit
Connect braking unit to P
and ,
and ensure an open circuit between
P
and D, and P and C.
(N terminal is built in L1c, L2c,
,
and R, S, T.)
P
: Connecting to (+) terminal of
V_BUS voltage.
: Connecting to (-) terminal of
V_BUS voltage.
two places
Ground terminal
Used to connect grounding wire of power supply and
servo motor.
Terminal
Identification
Terminal
Description
Notes
CN1
I/O connector
Used to connect external controllers. Please refer to
section 3.3 for details.
CN2
Encoder
connector
Used to connect encoder of servo motor. Please refer
to section 3.4 for details.
