Revision September 2013 1-1
Chapter 1 Unpacking Check and
Model Explanation
1.1 Unpacking Check
After receiving the AC servo drive, please check for the following:
Ensure that the product is what you have ordered.
Verify the part number indicated on the nameplate corresponds with the part number of
your order (Please refer to Section 1.2 for details about the model explanation).
Ensure that the servo motor shaft rotates freely.
Rotate the motor shaft by hand; a smooth rotation will indicate a good motor. However,
a servo motor with an electromagnetic brake can not be rotated manually.
Check for damage.
Inspect the unit to insure it was not damaged during shipment.
Check for loose screws.
Ensure that all necessary screws are tight and secure.
If any items are damaged or incorrect, please inform the distributor whom you purchased
the product from or your local Delta sales representative.
A complete and workable AC servo system should include the following parts:
Part I : Delta standard supplied parts
(1) Servo drive
(2) Servo motor
(3) 5 PIN Terminal Block (for L1c, L2c, R, S, T)
(4) 3 PIN Terminal Block (for U, V, W)
(5) 4 PIN Terminal Block (for P , D, C, )
(6) One operating lever (for wire to terminal block insertion)
(7) One jumper bar (installed at pins P and D of the 3 PIN Terminal Block for P , D, C)
(8) Instruction Sheets
