Chapter 7 Servo Parameters ASDA-B2
7-84 Revision September 2013
Display of Low Word: LXXXX: It indicates the fault code, i.e. alarm code.
Display of High Word: hYYYY: It indicates the CANopen error code.
P4-03★
ASH4 Fault Record (N-3)
Address: 0406H
0407H
Operation
Interface:
Keypad / Software Communication
Related Section:
Section 4.4.1
Default: 0
Control
Mode:
ALL
Unit: N/A
Range: N/A
Data Size: 32-bit
Display
Format:
Hexadecimal
Settings:
This parameter is used to set the fourth most recent fault record.
Display of Low Word: LXXXX: It indicates the fault code, i.e. alarm code.
Display of High Word: hYYYY: It indicates the CANopen error code.
P4-04★
ASH5 Fault Record (N-4)
Address: 0408H
0409H
Operation
Interface:
Keypad / Software Communication
Related Section:
Section 4.4.1
Default: 0
Control
Mode:
ALL
Unit: N/A
Range: N/A
Data Size: 32-bit
Display
Format:
Hexadecimal
Settings:
This parameter is used to set the fifth most recent fault record.
Display of Low Word: LXXXX: It indicates the fault code, i.e. alarm code.
Display of High Word: hYYYY: It indicates the CANopen error code.
P4-05
JOG JOG Operation
Address: 040AH
040BH
Operation
Interface:
Keypad / Software Communication
Related Section:
Section 4.4.2
Default: 20
Control
Mode:
ALL
Unit: r/min
Range: 0 ~ 5000
Data Size: 16-bit
Display
Format:
Decimal
