Delta Electronics ASDA-B2 series User Manual

Chapter 7 Servo Parameters ASDA-B2
7-102 Revision September 2013
Setting value: 0x13
DO Name DO Function Description
Trigger
Method
Control
Mode
SNL
(SCWL)
Reverse software limit. SNL is activated when the servo
drive has detected that reverse software limit is reached.
Level
Triggered
All
Setting value: 0x14
DO Name DO Function Description
Trigger
Method
Control
Mode
SPL
(SCCWL)
Forward software limit. SPL is activated when the servo drive
has detected that forward software limit is reached.
Level
Triggered
All
Setting value: 0x19
DO Name DO Function Description
Trigger
Method
Control
Mode
SP_OK
Speed reached output. SP_OK will be activated when the
speed error is equal and below the setting value of P1-47.
Level
Triggered
S, Sz
NOTE
1) When P2-18 to P2-22 and P2-37 is set to 0, it indicates output function is disabled.
