Delta Electronics ASDA-B2 series User Manual

ASDA-B2 Appendix A Accessories
Revision September 2013 A-13
3kW Servo Drive and 3kW Medium Inertia Servo Motor
Servo Drive ASD-B2-3023-B
Medium Inertia
Servo Motor
ECMA-E△1830□S
Motor Power Cable
(Without Brake)
ASD-CAPW220X
Motor Power Cable
(With Brake)
ASD-CAPW230X
Power Connector
ASD-CAPW2000
Encoder Cable
ASDBCAEN100X
Encoder Connector
ASDBCAEN1000
(X=3 means 3m; X=5 means 5m)
3kW Servo Drive and 3kW Medium/High Inertia Servo Motor
Servo Drive ASD-B2-3023-B
Medium/High Inertia
Servo Motor
ECMA-F△1830□S
Motor Power Cable
(Without Brake)
ASD-CAPW220X
Motor Power Cable
(With Brake)
ASD-CAPW230X
Power Connector
ASD-CAPW2000
Encoder Cable
ASDBCAEN100X
Encoder Connector
ASDBCAEN1000
(X=3 means 3m; X=5 means 5m)
Other Accessories (for ASDA-B2 series all models)
Description Delta Part Number
Communication Cable between Servo Drive
and Computer (for PC)
ASD-CARS0003
Regenerative Resistor 400W 100Ω BR400W040
Regenerative Resistor 1kW 1000Ω BR1K0W020
NOTE
1) () at the ends of the servo drive model names are for optional configurations (Full closed-loop,
CANopen and extension DI port). For the actual model name, please refer to the ordering information of
the actual purchased product.
2)
(△) in the model of servo motor indicates the encoder mode. △ =1: increment, 20-bit; △ =2:
increment, 17-bit.
3) () in the servo motor model names are for optional configurations (keyway, brake and oil seal).
