Chapter 3 Connections and Wiring ASDA-B2
3-8 Revision September 2013
Terminal
Identification
U
(Red)
V
(White)
W
(Black)
CASE GROUND
(Green)
BRAKE1
(Blue)
BRAKE2
(Brown)
A 1 2 3 4 - -
B 1 2 4 5 3 6
C F I B E G H
D D E F G A B
When selecting the wire rod, please choose 600V PVC cable and the length should not longer
than 30m. If the length exceeds 30m, please take the received voltage into consideration when
selecting the wire size. Please refer to Section 3.1.6 for wire rod selection.
NOTE
1) The coil of brake has no polarity. The names of terminal identification are BRAKE1 (Blue) and
BRAKE2 (Brown).
2) The power supply for brake is DC24V. Never use it for VDD, the +24V source voltage.
3) Box, () in servo motor model represents brake or keyway / oil seal.
