Chapter 3 Connections and Wiring ASDA-B2
3-14 Revision September 2013
Encoder Cable
Servo Drive
Encoder Cable - Wire Gauge AWG (mm
2
)
Wire Size Core Number UL Rating
Standard Wire
Length
ASD-B2-0121- 0.13 (AWG26) 10 core (4 pair) UL2464 3m (9.84ft.)
ASD-B2-0221- 0.13 (AWG26) 10 core (4 pair) UL2464 3m (9.84ft.)
ASD-B2-0421- 0.13 (AWG26) 10 core (4 pair) UL2464 3m (9.84ft.)
ASD-B2-0721- 0.13 (AWG26) 10 core (4 pair) UL2464 3m (9.84ft.)
ASD-B2-1021- 0.13 (AWG26) 10 core (4 pair) UL2464 3m (9.84ft.)
ASD-B2-1521- 0.13 (AWG26) 10 core (4 pair) UL2464 3m (9.84ft.)
ASD-B2-2023- 0.13 (AWG26) 10 core (4 pair) UL2464 3m (9.84ft.)
ASD-B2-3023- 0.13 (AWG26) 10 core (4 pair) UL2464 3m (9.84ft.)
NOTE
1) Please use shielded twisted-pair cables for wiring to prevent voltage coupling and
eliminate electrical noise and interference.
2) The shield of shielded twisted-pair cables should be connected to the SHIELD end
(terminal marked
) of the servo drive.
3) In order to prevent fire hazard and accidents, please form the wiring by following the
cable specifications outlined above.
4) The boxes (
) at the ends of the servo drive model names represent the model type of
ASDA-B2 series. For the actual model name, please refer to the ordering information of
the actual purchased product.
5) The boxes (
) in the servo motor model names are for optional configurations (keyway,
brake and oil sea).
