ASDA-B2 Chapter 4 Display and Operation
Revision September 2013 4-7
NOTE
1) Dec. represents Decimal display and Hex. represents Hexadecimal display.
2) The above display methods are both available in monitor mode and parameter setting mode.
3) All monitor variables are 32-bit data. The users can switch to high byte or low byte and display
format (Dec. or Hex.) freely. Regarding the parameters listed in Chapter 8, for each
parameter, only one kind of display format is available and cannot be changed.
