圖4-7 : 通訊模組示意圖
RPI M50A機種之通訊模組請參考圖4-7。此模組提供VCC、RS-485、乾接點、
緊急關機、以及數位輸入等不同功能之連接端子。
** 請使用外徑20 AWG (0.5mm²)的電纜線。 **
4.4 通訊介面之連接
Dry Contact
VCC & RS-485 EPO*1 &
Digital Inputs*6
Terminal Resistor
176
配線
