Delta RPI Series - Appendix B: Assembly Note

Appendix B: Assembly Note
①
③
②
NO Location Screw torque
5 SPD board 8 Kgf-cm (0.8N-m)
4 Fans 8 Kgf-cm (0.8N-m)
2 Air inlet 8 Kgf-cm (0.8N-m)
3 Fan panel 8 Kgf-cm (0.8N-m)
1 Front cover 10 Kgf-cm (1N-m)
Appendix B-1 : Assembly Note-1
③
④ ④
⑤
Appendix B: Assembly Note
