Figure 5-11 : Insulation page
Figure 5-12 : Country page
Before connecting to grid, inverter will measure the impedance between the PV
array and PE first. M50A models provide 4 types of impedance measurement
methods (ON, Plus Grounded, Minus Grounded, and OFF) and 2 impedance
limits. Installer must select the appropriate method based on PV array’s wiring.
Each country has its own electricity regulations. Installer must select the country
correctly.
Inverter ID: 002
Insulation
Country
Grid Settings
►
Mode: ON
Resistance: 250kΩ
►
ON
Plus Grounded
Minus Grounded
OFF
►
Mode: ON
Resistance: 250kΩ
►
150kΩ
250kΩ
1100kΩ
►
EXIT
EXIT
EXIT
EXIT
ENT
ENTENT
Inverter ID: 002
Insulation
Country
Grid Settings
►
AU/NZ
Austria
Belgium
China
►
EXIT
ENT
5.2.7.2 Insulation
5.2.7.3 Country
