75
Advanced Operation
4. Monitor TV (TV),digital broadcast satellite
(DBS) tuner and cable (CABLE) system
buttons
SRC ON : Power on / Standby
SETUP : Setup
TOP :Top menu
MENU : Menu
RTN : Return
c, d, b, a : Cursor up, down, left and right
ENTER : Enter
DISP : Switch display
CH +, – : Switch channels +, –
0 ~ 9, +10 : Number
TV/VCR : Switch between TV and video player
•, ª :Volume up/down
The preset codes of cable box decoder can be
recorded in the DBS mode so that the cable device can
be operated ( page 72, 73).
It is only possible to set the preset memory for either
the DBS or cable device.
3. Video deck (VCR-1/VCR-2) system buttons
SRC ON : Power on / Standby
6, 7 : Manual search (forward and reverse)
2 : Stop
1 :Play
3 : Pause
0 ~ 9, +10 : Number
To Next Page
