CVIC - MODCVIC - MULTICVIC
2 - «PARAMETERS» Menu
The «PARAMETERS» menu allows you to:
- display the tool features «SPINDLE» menu
- correct the parameters of the cycle «CYCLES» menu»
- dedicate the application «STATION» menu
- program the PC connection «PC LINK» menu
2.1 - «SPINDLE» Menu
Menu: MAIN\PARAMETERS\SPINDLE.
This menu displays the features of the controller and the features read in the tool memory.
The data cannot be changed.
2.2 - «QUICK CYCLE» Menu
Menu: MAIN\PARAMETERS\QUICK CYCLE.
It is accessible when no cycle has been saved in the tool memory. This menu allows you to program a cycle without
running the LEARNING sequence. By default, the quick cycle contains a run down speed phase and a final speed
phase. The operator only programs the target torque and the maximum angle on the screen.
To do so, select a cycle and press .
For the programming procedure, refer to paragraph 3.1.3.
It is the controller itself which calculates the speeds and all of the other default parameters (minimum speed, maximum
speed, etc.).
In the version L CVIC, the tightening cycle is stored in the tool memory and corresponds to cycle «0» (zero). It can
include 3 phases: approach, run down speed and final speed phase. Only the run down speed and final speed phases
are optimised automatically with the «Learning» and «Quick cycle» programming modes. The approach phase must
be inserted and programmed manually. See next pages for the description of the cycle and phases.
2.3 - «CYCLES» Menu
Menu: MAIN\PARAMETERS\CYCLES.
It is accessible when a quick cycle has been saved in the tool memory, using one of the LEARNING or QUICK
CYCLES programming methods.
It allows you to change the parameters of the Run down speed and Final speed phases obtained in the 2 programming
modes.
It allows you to insert an approach phase.
See next pages for the description of the cycle and phases.
2.4 - «STATION» Menu
Menu: MAIN\PARAMETERS\STATION.
The «STATION» menu allows you to configure the following parameters:
Unit Nm/FtLb/InLb/Kgm/Kgcm.
Rv speed this speed is used at each run reverse command by the operator (the run reverse speeds used during
the cycle may be programmed in each phase or in each cycle as the case may be. (See further in this
manual).
Directio direction: Right/Left.
Lock.NOK When this function is enabled, the system locks the start cycle as soon as the number of cycles run
with an accept report has reached the programmed «NCYOK». A reset command must be sent to
unlock the cycle start.
Scy pulse start cycle by pulses: the «start cycle» signal is activated by a pulse. For safety purposes, this
parameter is only available on fixed spindles.
