3.2.3 - Programming the Phases
After selecting a cycle, the cursor will move to the line where the various phases of the selected cycle are shown.
You will be allowed to modify, insert or delete a phase.
Creating (or changing) a phase:
Using and , select the phase that you want to change.
To change a phase, press to select "Mod". Press to validate.
The phase type is highlighted. Use and to select the phase type. Press to validate.
Inserting a phase
To insert a phase in a cycle already programmed, you must proceed as follows:
1 - Create a blank before the phase before which you want to insert a new phase.
For this purpose, position the cursor on the phase before which you want to insert a new phase.
Select "Ins" by pressing then .
Press to validate.
2 - Proceed as before to create a phase.
To change a phase, press to select "Mod". Press to validate.
The phase type is highlighted. Use and to select the phase type.
Press to validate.
Deleting a phase
Position the cursor on the phase that you want to delete.
Select "Del" by pressing then . Press to validate.
