Desoutter CVIC - CALIBRATION Menu; SPINDLE AUTO Menu; SPINDLE MANU Menu

6159932010-09
42 / 60
English
CVIC - MODCVIC - MULTICVIC
1.4 - «CALIBRATION» Menu
The calibration procedure is recommended to compensate for any possible drift of the tool torque or after each change
of tool element.
1.4.1 - «SPINDLE AUTO» Menu
Important: the tool will be tuned over its entire operating torque range.
Equipment required: - a torque measuring unit DELTA4000 connected to the CVIC controller via a serial
cable.
- the tool to be calibrated with a transducer and its cable.
Program the measuring unit by pressing / to display "standard" in the summary line then to
display "Calib CVIC".
Select the type of transducer to be used by pressing then / .
If the measuring unit is not correctly connected or programmed, an error message «Wait. for conn.» is displayed
on the screen.
Follow the instructions displayed on the CVIC screen. 10 tests can be run and they are performed at various
increasing speeds. Run one test after another.
Warning: the tightening is performed up to the MAX. torque.
Press to validate the writing in the tool memory.
1.4.2 - «SPINDLE MANU» Menu
This menu is used to manually calibrate the tool to the torque value of the selected cycle. The torque transducer
inserted in line with the tool can be connected to any measuring unit in the CP range. Run a tightening cycle
5 times and manually enter the values read on the standard instrument.
Warning: The torque and angle reports MUST be correct to allow the procedure to be processed in normal
conditions.
The «Reset value» key resets the readings.
The «Reset coeff.» key displays coefficient 1 by default.
Depending on the option selected (K.Torque/spindl or K.Torque/cycle) in the «STATION» menu (see § 6 -3.5),
the sensitivity correction coefficient is saved:
- either in the tool memory.
- or in the controller.
