CVIC - MODCVIC - MULTICVIC
The electric tightening system is automatically controlled by measuring the power consumption of the tool and monitoring
the angle rotation. This technology provides a complement to the range of traditional systems fitted with a torque transducer.
The electric power tool is either hand held (EC) or fixed (MC, MCL).
In order to familiarise yourself with the keyboard of the controller, refer to section 1.2 in this manual,
which explains the procedure that will allow you to program the various parameters of the controller.
SECTION 2 - INTRODUCTION
1 - CVIC Controller
The CVIC controller is available in normal mode and in ECPHT mode (high run down speed and a high torque).
The normal mode covers two controller models (-2 and -4) in two versions each (L and H).
Main differences between versions LH
Programming modes:
Quick cycle 
Automatic programming 
Number of cycles 0 15
1 cycle in the tool 
Number of phases available 3 15
Normal mode Normal mode ECP HT mode
CVIC L-2
CVIC H-2
CVIC L-4
CVIC H-4
CVIC H-4
To control tools with a
very low torque
To control the other tools in the range,
except for ECP HT tools
To control ECP HT tools
(High Torque)
Handheld tools Fixed tools Handheld tools Fixed tools Handheld tools
ECP3L / ECF3L
ECP5L / ECF5L
ECP10L/ECF10L
ECP20L/ECF20L
ECP3LT
ECP5LT
ECP10LT
ECP20LT
ECP5
ECL1
ECL3
ECL5
ECL8
ECL11
ECLA1
ECLA3
ECLA5
ECLA8
ECLA11
ECD5
ECA15
MC35-10 ECP20S/ECF20S
ECP30S/ECF30S
ECP20
ECP30
ECP40S
ECD20
ECD30
ECD50
ECD70
ECD120
ECA20
ECA30
ECA40
ECA60
ECA70
ECA90
ECA115
ECA125
ECA150
ECA200
MC35-20
MC38-10
MC38-20
MC51-10
MC51-20
MC60-10
MC60-20
MC60-30
MC80-10
MC80-20
MC80-30
MC80-40
MC106-10
MC106-20
MCL38-20
MCL51-20
MCL60-20
MCL60-30
MCL80-40
MC24-20 OF
MC26-50 OF
MC30-80 OF
MC36-140 OF
MC40-115 OF
ECP190
ECP550
ECP950
ECPHT
