6159932010-09
41 / 60
English
CVIC - MODCVIC - MULTICVIC
1 - «MAINTENANCE» Menu
1.1 - «TEST» Menu
The»START SPINDLE» menu allows you to check the correct operation of the tool.
Select the speed and rotation direction («Directi» reverser for a hand held tool or in the menu for a fixed tool) then
press the trigger for a hand held tool of EC type or press the «on» button for a fixed tool of MC or MCL type.
Select «Reset» to reset the display.
Select «Ventil.» to start the fan and check its working order.
The «INPUT/OUTPUT» menu allows you to check the status of inputs, and to test the outputs and the LEDs on the
front panel.
Testing the outputs:
The cursor blinks on output 1. Press to move the cursor and to validate the box or not. The selected output
is or is not enabled. Then it is possible to check the efficiency of the status change of this output on the corresponding
input, for example on the PLC. Use the same procedure to check that the Max, OK and Min LEDs glow correctly.
1.2 - «CHANNEL TEST» Menu
This menu is used to test the operation of the controller and tool.
There is a sequence of two tests: - reading the information contained in the tool memory.
- checking the servodrive board.
If an error arises, a message is displayed. Press to display an additional error message.
1.3 - «COUNTERS» Menu
This menu allows the maintenance technician to know the number of cycles run.
The «Controller» counter shows the number of cycles run since delivery.
The «Tot.» total) and «Par.»(partial) counters show the number of cycles run by the tool.
Select «Reset» to reset the partial counter of the tool.
SECTION 7 - MAINTENANCE OF THE CVIC CONTROLLER
This section helps the maintenance operator to:
- check that the controller+tool assembly operates correctly.
- know the number of cycles run.
- tune the system manually or automatically.
- adjust the contrast of the display, update controller date, select the language and program an access code.
- change the memory battery.
