CVIC - MODCVIC - MULTICVIC
Programming the parameters
Using and , position the cursor on the phase whose parameters you want to program.
Press .
Search Sequence Phase (H)
The maximum time is simply displayed for the Search sequence phase as it is implicitely equal to the number
of rotations multiplied by the rotation time + stop time.
Int.time time programmed between this phase and the next one: 0 - 20 s.
Nb rotat. number of rotations: 1 - 9.
Stop time stop time: 0 - 20 s.
Rotat.Typ rotation type: Time/Angle.
Rot.time rotation time: 0 - 50 s.
or
Rot.angl. rotation angle: 0 - 9999°.
Direction Right/Left/Alter. If the direction is alternate, half the rotations are clockwise and the
other half are in the opposite direction.
Speed rotational speed: 0 - 100 %.
Accelerat 0 - 20 s. Acceleration or deceleration time to switch from one speed to another. This parameter
is enabled for the first phase and when the interphase time is not equal to zero. When
the interphase time is equal to zero, acceleration is optimised automatically.
Power1-100 %
No phase RP.
Angle Rundown Phase (L - H)
It allows you to quickly approach the fastener without reaching the joint. It is particularly recommended in the
case of hard joints for which the approach speed should be restricted in order to control the final torque.
Int.time time programmed between this phase and the next one: 0 - 20 s.
N.rotat. number of rotations performed by the tool during this phase: 0 - 100.
Max Tmaximum torque that should not be reached at the end of the phase:
0 Nm to max. value of the spindle.
Safety T safety torque. Stops the spindle if reached during the phase. Stops the spindle if reached during
the phase.
Other...
Press .
Motor settings: «MOTOR PARAM.»
Thread Right/Left.
Speed rotational speed: 0-100%.
Acceler 0 - 20 s. Acceleration or deceleration time to switch from one speed to another. This parameter
is enabled for the first phase and when the interphase time is not equal to zero. When
the interphase time is equal to zero, acceleration is optimised automatically.
Reset The Reset function allows you to reset the torque and/or angle values at the beginning of the current
phase.
External stopYes/No The following conditions must be met for the system to stop the current phase and shift
to the next one:
- the «External stop» parameter must be on «yes» in this screen.
- the signal at the «External stop» input of the Input/Output connector must shift to «1».
The phase RP is OK if:
- the torque is lower than the programmed maximum torque
and
- if the programmed number of rotations has been reached.
