Desoutter CVIC - Page 29

6159932010-09
29 / 60
English
CVIC - MODCVIC - MULTICVIC
Run Down Speed Phase in ECPHT mode
Max.time maximum phase running time. 0.01 - 99 s.
Int.time time programmed between this phase and the next one: 0,10 s minimum.
Prevailing Yes/No
An offset will be added to the target torque during this phase.
Other...
Press .
Motor settings: «MOTOR PARAM.»
Thread Right/Left.
Speed rotational speed: 0 - 100 %.
Acceler 0 - 20 s Acceleration or deceleration time to switch from one speed to another. This parameter
is enabled for the first phase and when the interphase time is not equal to zero. When
the interphase time is equal to zero, acceleration is optimised automatically.
Reset The Reset function allows you to reset the torque and/or angle values at the beginning of the
current phase.
External stop Yes/No The following conditions must be met for the system to stop the current phase and shift
to the next one:
- the «External stop» parameter must be on «yes» in this screen.
- the signal at the «External stop» input of the Input/Output connector must shift to «1».
No phase RP.
Final Speed Phase (L - H)
Max.time maximum phase running time. 0.01 - 99 s.
Int.time time programmed between this phase and the next one: 0 - 20 s.
Tightening strategy: Torque/Torque+Angle.
Additional strategy for version H: Angle+Torque.
Min T minimum torque: 0 Nm to max. value of the spindle.
Target T target torque: 0 Nm to max. value of the spindle.
Max T maximum torque: 0 Nm to max. value of the spindle.
Threshol angle threshold: 0 Nm to max. value of the spindle.
Min A minimum angle: 0 - 9999°.
Max A maximum angle: 0 - 9999°.
Safety A safety angle: 0 - 9999°.
Other...
Run Down Speed Phase (L - H) in normal mode
Max.time maximum phase running time. 0.01 - 99 s.
Int.time time programmed between this phase and the next one: 0 - 20 s.
Target T target torque: 0 Nm to max. value of the spindle (screw approach torque).
Other...
Press .
Motor settings: «MOTOR PARAM.»
Thread Right/Left.
Speed rotational speed: 0 - 100 %.
Acceler 0 - 20 s Acceleration or deceleration time to switch from one speed to another. This parameter
is enabled for the first phase and when the interphase time is not equal to zero. When
the interphase time is equal to zero, acceleration is optimised automatically.
Reset The Reset function allows you to reset the torque and/or angle values at the beginning of the
current phase.
External stop Yes/No The following conditions must be met for the system to stop the current phase and shift
to the next one:
- the «External stop» parameter must be on «yes» in this screen.
- the signal at the «External stop» input of the Input/Output connector must shift to «1».
No phase RP.
ECPHT
