Press .
Motor settings: «MOTOR PARAM.»
Thread Right/Left.
Speed rotational speed: 0 - 100 %.
Acceler 0 - 20 s. Acceleration or deceleration time to switch from one speed to another. This
parameter is enabled for the first phase and when the interphase time is not equal to
zero. When the interphase time is equal to zero, acceleration is optimised automatically.
Reset The Reset function allows you to reset the torque and/or angle values at the beginning of
the current phase.
External stop Yes/No The following conditions must be met for the system to stop the current phase and
shift to the next one:
- the «External stop» parameter must be on «yes» in this screen.
- the signal at the «External stop» input of the Input/Output connector must shift to «1».
Detailed RP. See tightening strategies (torque, torque + angle, angle + torque and prevailing torque) in
Appendix .
Action on NOK Phase (H)
When a report is rejected (max. torque or angle reached, etc.), it is possible to apply a specific corrective action
to the cycle, either by stopping the cycle or by programming a corrective phase.
For example: untighten the screw, repeat tightening, etc.
You must choose first: - the fault(s) to which you want to apply a corrective action.
- the number of tests (from 1 to 99).
Various actions on NOK are available:
End to stop the tightening cycle.
Rrv.+End a Run Reverse phase is run according to the programmed time then the cycle is stopped.
Jump the cycle proceeds to the indicated phase.
Rrv.+Jump a run reverse phase is run according to the programmed time, then the cycle proceeds to
the indicated phase.
Rv time Run reverse time: 0 - 99 s.
Thread Right/Left.
No phase RP.
Run Reverse Phase (H)
Max.time Phase running timeout: 0.01 - 99 s.
Int.time time programmed between this phase and the next one: 0 - 20 s.
Strategy Torque/Torque+Angle/Angle+Torque.
Min T minimum torque: 0 Nm to max. value of the spindle.
Target T target torque: 0 Nm to max. value of the spindle (torque or torque + angle strategy).
Max T maximum torque: 0 Nm to max. value of the spindle.
Safety T safety torque: 0 Nm to max. value of the spindle.
B-away T breakaway torque: starts the torque control (strategies: torque or torque + angle). Must be
higher than final torque.
Threshol angle threshold: 0 Nm to max. value of the spindle.
Min A minimum angle: 0 - 9999°.
Target A target angle: 0 - 9999° (angle + torque strategy).
Max A maximum angle: 0 - 9999°.
Other...
