6.1.4 Module and Port Errors
Up to 16 amplifier modules can be installed in the DEV 2190. The different
functionalities of the modules (or of the module ports) are monitored. Error
indication is provided for the functionality of the amplifiers, for the temperature,
for the amplifier supply current, for the RF level functionality, and for the LNB
power (or bias) current monitoring functionality.
Error
Code
Description
Decimal
Hexadecimal
30976…30991
0x7900…0x790F
Amplifier [i] (i = {1…16})
31232…31247
0x7A00…0x7A0F
Overtemp Module [i] (i = {1…16})
31488…31503
0x7B00…0x7B0F
Overcurr Module [i] (i = {1…16})
31744…31759
0x7C00…0x7C0F
RF Sense Port [i] (i = {1…16})
36864…36879
0x9000…0x900F
Bias Limit Port [i] (i = {1…16})
6.1.5 Other Errors
For the sake of completeness, the other error codes that might be reported by the
device are listed here. If experiencing one of these errors, please contact
DEV Systemtechnik for assistance.
Error
Code
Description
Decimal
Hexadecimal
2560
0x0A00
Internal
16384
0x4000
System Setup/Config
