User Manual DEV 2190
Copyright DEV Systemtechnik GmbH 2009-2017 95
9 Spare Parts
CPU Module (without SD-card) (up to Rev. 5) DEV 14-0100
CPU Module (Rev. 6 or higher) DEV 14-0119
Power Supply Module; 100…240 V AC DEV 12-0020
Fan Module (up to Rev. 3) DEV 17-0023
Fan & Monitoring Module (Rev. 4 or higher) DEV 17-0042
Fan Filter DEV 78-0032
Amplifier Modules
Amplifier modules are required as spare parts if defective modules are to be
exchanged or if a functionality (e.g. an IRD controlled switch option) is to be
enabled which was ordered in combination with a (number of) Option 26 (upgrade
option, please refer to chapter 3.1.8).
Note, that in the following amplifier module selection bullet points "zz" is used as a
placeholder for "50", "50-75", "50-50-75", or "75" indicating that the impedance of the
option is not relevant.
Amplifier modules with one RF output port are required for:
• Amplifier options: Option 1/zz
• Distribution options: Option 2*4/zz (2 amplifier modules), 8/zz, 128/zz;
• Combiner options: Option 2*C4/zz (2 amplifier modules), C8/zz, C16/zz
• IRD controlled switch options (2 or 4 amplifier modules per IRD controlled
switch option): Option 2x16/zz, 4x16/zz, 2x32/zz, 4x32/zz
Amplifier modules with two RF output ports are required for:
• Amplifier options: Option 2/zz
• Distribution options: Option 16/zz, 32/zz, 64/zz
• IRD controlled switch options (2 or 4 amplifier modules per IRD controlled
switch option): Option 2x48/zz, 4x48/zz, 2x64/zz, 4x64/zz
• Redundant amplifier options (2 amplifier modules per redundant amplifier
option): 23/zz, 24/zz
Please specify the amplifier module by selecting the appropriate part number:
Amplifier Module (with one RF output port) DEV 11-0096
Amplifier Module (with two RF output ports) DEV 11-0081
Switch Module for Redundant Amplifier Options
Redundancy Switch Module DEV 11-0090
