Creating a MODELA Player 4 File
100
5-2.
Input the hole location and depth.
“Perfume.stl”: [X : 40] [Y : 0 ][Z : 0 ][D : 5 ]
The depth of hole drilling
Set “Depth” to around half the length (5 mm) of the positioning
pin used when reversing the object.
Points to note when determining hole position
Material is xed rmly.
Do not set outside the width of material.
Do not set within cutting area.
NGOK
NGNG
NGNG
To Next Page
