8/ INSTALLATION
OPERATOR'S MANUAL
Dj SEED MANAGER® SE PLANTER MONITOR
BENCHMARK Series® 11001-1218-200112 Rev A
Power
Cable
Black
Red
Black
Red
6V
6V
12V
Powe
r
Cable
Vehicle
Ground
Vehicl
e
Ground
Figure 4
12 Volt Battery Source Connections
Figure 5
24 Volt Battery Source Connections
Figure 6
Negative or Positive Sources Connections
