OPERATOR'S MANUAL
INSTALLATION/ 7
Dj SEED MANAGER® SE PLANTER MONITOR
BENCHMARK Series® 11001-1218-200112 Rev A
side of the tractor opposite the alternator
and spark plugs. Locate the harness to
prevent being pinched, cut, or stepped
on and secure it with wire ties.
STEP 2
Install or connect an existing ground
speed sensor. The ground speed sensor
may be one of three types  radar,
reluctance, or Hall Effect. A radar
sensor or reluctance sensor connects
directly to the designated connector on
the primary harness. A Hall Effect
sensor may require an adapter harness
to connect to the primary harness.
Sensor mounting instructions accompany
the sensor. Select the mounting location
and install as the instructions describe.
STEP 3
Follow instructions to install Module and
Sensor Harnessing in Implement
Harness section.
STEP 4
The power connections are made last to
avoid accidental shorts during harness
installation.
The Seed Manager® SE System
operates on 12 volts DC only. The
battery connections on the primary
harness consist of two wires, each
terminated with a ring terminal.
Before making the battery connections,
determine the tractor battery arrange-
ment from Figures 4, 5, and 6, found on
page 8. After the 12 volt source is
known, connect the black wire directly to
the negative (-) terminal of the battery.
The red wire (containing the fuse link)
connects directly to the positive (+)
battery terminal. Make sure the connec-
tions are clean and tight. Do not route
these wires in close proximity to the
existing battery cables. Secure the battery
wires with wire ties.
If your tractor battery arrangement
differs from those shown in Figures 4, 5,
and 6, or if in any doubt exists about
how to connect to the battery, use a
voltmeter first. Verify 11 to 14 volts
across the battery connection points. On
Tractors using two batteries, be sure to
make connections to the grounded
battery.
Note: Due to the power require-
ments for the Seed Manager® SE
system, the battery connections must
be made directly to the tractor
battery.
WARNING:
Before welding on the frame or chassis, be
certain to disconnect battery leads.
