Dickey-John Seed Manager SE User Manual

10/ INSTALLATION
OPERATOR'S MANUAL
Dj SEED MANAGER® SE PLANTER MONITOR
BENCHMARK Series® 11001-1218-200112 Rev A
In this four module setup, two modules are connected to P1 and two to P2.
P1
P2
b1 b2 b3 b4
InOutInOut In Out In Out
In this three module setup, all modules are connected to P1.
InOutInOut
InOut
P1
b1 b2
b3
In this three module setup, one module is connected to P1 and two are connected to
P2.
InOutInOut
InOut
P1
b1
b2
b3
P2
Figure 6A
Four module setup
Figure 6B
Three module setup
Figure 6C
Three module setup
