Digi Connect Series

Hardware System statusLEDs
Digi Connect Family and ConnectPort TSFamily
158
Item Description
Ethernet port
Configure the Ethernet port.
USB ports
Usethe USB port to connect a flash drive to the
device. You can use the flashdrv command to view
information about the flash drive.
Power Connector Connect a power source to the device.
Reset button
Reset thefactory settings on a Digi Connect and
ConnectPort TSFamily product using the Reset
button.
LEDs: ConnectPort TS8/16
LED/button
Color and Light
Pattern Description
Power LED Solid Green Power on.
Diag LED Amber Blinksduring product initialization and factory
reset, using the light patternsbelow. ThisLED
should never blink during normal operation. If it
blinksconstantly, contact Digi Technical
Support.
1-1-1blinking
amber
Initializing firmware.
1-5-1blinking
amber
Device configuration has been restored to its
factory defaults.
Other blinking
amber
Contact Digi Technical Support.
Solid amber Device ispowered on and ready for operation.
C1 and C2 LEDs Green You can use these LEDswith custom applications
running on the unit.
Reset button N/A Performsequivalent of apower-cycle.
Serial TX Yellow Serial port istransmitting data.
Serial RX Green Serial port isreceiving data.
Ethernet Link LED Solid green Ethernet link isup. Will light solid green when an
active LAN connection isplugged into the
Ethernet port.
Ethernet Activity LED Blinking yellow Blinkswhen active traffic is on theLAN
connection.
