Digilite Pulse MX - Page 7

7
PULSE MX
422
288
105
692
288
105
Connections
• DMX out: 2 x XLR-3p; 2x XLR-5p; 1x RJ45 Art-net
• DMX in: 1 x XLR-5p
• SMPTE in: 1x XLR-3p
• MIDI in/out/thru: DIN-3p
• Backup and memory: USB port
• Service light: 1x USB port
• PULSE-EX wings: 2x RJ12
Dimensions and weight
• Net weight: 12 kg
• Dimensions: 692x288x105 mm
PULSE EX
DESCRIPTION
PULSE-EX is a playback wing for PULSE-MX DIGILITE console, conceived to oer a wider surface of avail-
able controls. The playback wing PULSE-EX is composed by 12 programmable fader, 12 control buttons
and 24 playback key. PULSE-EX connects to PULSE-MX via cable, no extra software required, just connect
the Wing to the console and the Playbacks are ready to control your show.
TECHNICAL SPECIFICATIONS
• 2 backlit LCD display with 72 characters (2 lines x 36 digits) to show the fader congurations
• 12 controllers buttons for direct access to playback and programming functions
• 12 faders with key buttons individually congurable as Playback master, Group master, Manual Cue
• 24 keys for direct access to playback registers
• Power supply directly from PULSE-MX
• Weight: 5kgs
