- 6 - SMPTE TIMECODE
The SMPTE timecode is a signal which contains a time identication in the hours:minutes:seconds frame
format; it was invented in the cinematographic industry to synchronise audio and video and is ideal for
solving general synchronisation problems.
The console is capable of receiving a SMPTE signal generated by a SMPTE master (the device which
stores the reference clock for synchronisation) and activating certain events at predened times.
Buttons:
Edit:
puts the list in edit mode. When the Edit button is active, you can edit the list eliminating or editing
the activation times of single events.
Record:
puts the list in record mode. When the Record button is active, all the events which occur in the con-
sole are added to the list (limited to the types recognised by the programme)
Play:
puts the list in play mode. When the Play button is active, each event is compared against the smpte
time and potentially activated.
Unselect all:
deselects all events (valid only in Edit mode)
Smpte window
1. Selection led: O=not selected event,
Red=selected event
2. Trigger led: Green=triggered event, O=not
triggered event
3. Event activation times in Hours-Minuts-seconds-
Frames
4. Real time smpte clock
Fig.52
