DG-GS1528HP User Manual
Show current authenticating type
•
802.1x: Use IEEE 802.1X to do authenticating
•
MAC-Based: Use MAC-Based authentication to do
authenticating.
•
WEB-Based: Use WEB-Based authentication to do
authenticating.
Show host authentication session status
•
IP version (IPv4, IPv6)
•
Disable: This session is ready to be deleted
•
Running: Authentication process is running
•
Authorized: Authentication is passed and getting network
accessibility.
•
Unauthorized: Authentication is not passed and not getting
network accessibility.
•
Locked: Host is locked and do not allow to do
authenticating until quiet period.
•
Guest: Host is in the guest VLAN.
Shows host operational VLAN ID.
Operational
(Session Time)
In “Authorized” state, it shows total time after
authorized.
In “Authorized” state, it shows how long the host do not
send any packet.
In “Locked” state, it shows total time after locked.
Shows VLAN ID given from authorized procedure.
